Product Details
It is used for personalized perforation of leather products like shoes、 bags、 belts、 sofas、 etc.It can punch 4- 6 different patterns in the same leather piece; suitable for leather processing and perforation workshopes.
Perforation samples
Machine parameters
| 型号 Model |
A2-G2-R4-5060 | A2-G2-R4-6080 | A2-G2-R6-5060 | A2-G2-R6-6080 |
| 型号说明 Model Specification |
双工位八冲杆高速机 2station 4heads Highspeed |
双工位八冲杆高速机 2stations 4heads Highspeed |
双工位十二冲杆高速机 1 station 12 heads Highspeed |
双工位十二冲杆高速机 2stations 12 heads Highspeed |
| 冲孔速度(孔/分钟) perforation speed(holes/min) |
1200x2 | 1200X2 | 1200x2 | 1200X2 |
| 冲杆数量(pcs) Head quantity |
4X2 | 4x2 | 6X2 | 6x2 |
| 旋转杆数量(pcs) Rotary head quantity |
4X2 | 4x2 | 6X2 | 6x2 |
| 孔径范围(mm) Hole size |
0.8~12 | 0.8~12 | 0.8~12 | 0.8~12 |
| 材料厚度(mm) Material thickness |
1~6 | 1~6 | 1~6 | 1~6 |
| 冲孔精度(mm) perforation precision |
0.2 | 0.2 | 0.2 | 0.2 |
| 机器功率(kW) Machine power |
220V/1.5kW | 220V/2.5kW | 220V/1.5kW | 220V/2.5kW |
| 电源频率(Hz) Power frequency |
50/60 | 50/60 | 50/60 | 50/60 |
| 压缩空气(bar) Compressed air |
5~6 | 5~6 | 5~6 | 5~6 |
| 机器净重(kg) Machine net weight |
1400 | 1565 | 1565 | 1655 |
| 机器毛重(kg) Gross weight |
1500 | 1665 | 1665 | 1755 |
| 机器尺寸(mxmxm) Machine size |
2.16X1.60X1.73 | 2.38x1.73x1.73 | 2.38x1.73x1.73 | 2.54x1.73x1.73 |
| 木箱尺寸(mxmxm) Wood packing size |
2.26x1.70x1.83 | 2.48x1.73x1.83 | 2.48x1.83x1.83 | 2.64x1.83x1.83 |
